Horizontal Submerged Centrifugal Pump

15000.00 - 25000.00 INR

Get a Price/Quote

Product Details:

Material Matel
Suction Type Single
Power Source Electric
Application Sewage Submersible
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Horizontal Submerged Centrifugal Pump Price And Quantity

Minimum Order Quantity 2 Piece
Price Range 15000.00 - 25000.00 INR

Horizontal Submerged Centrifugal Pump Product Specifications

Application Sewage Submersible
Suction Type Single
Power Source Electric
Material Matel

Horizontal Submerged Centrifugal Pump Trade Information

Payment Terms Cash in Advance (CID) Cheque Cash Advance (CA)
Supply Ability 500 Piece Per Month
Delivery Time 1 Week
Main Export Market(s) Western Europe Eastern Europe Central America Africa Middle East South America Australia Asia North America
Main Domestic Market All India

Product Description

Jasco Pump Pvt. Ltd. is an ISO 9001:2000 certified company that manufactures and exports Horizontal Submerged Centrifugal Pump, produced by highly skilled technocrats utilizing quality components and latest techniques. This pump is known for its radial suction port and radial discharge port.

Features:

The centrifugal pump requires minimal maintenance
This is a highly efficient pump that has an extended wear life
It has a grease lubricated bearing

Applications

Steel & cement plants
Water supply scheme
Irrigation schemes
Lifting raw water from Canel, river, dam or check dam, large lakes and other sources
Water effluent & treatment plant
Pots & docks
Irrigation schemes
Underground pits to overhead tanks

Technical Specification

Pump	Discharge Sizes	50 To 400 Mm
	Flow Rate Capacity	Up To 2000 M3/Hr.
	Head Capacity	Up To 120 Mtr.
Motor
	Speeds	750/1000/1500/3000 (SYNCHRONOUS Speed)
	Duty/Enclosures	S1/ Better Than Ip68
	Supply Condition	3ø, 415v,690v, 50 Hz. A.C. Supply 3ø, 415v,550v, 60 Hz. A.C. Supply

Description	Material
Cable	Cu. + PVC
Cable protector	Nitrial Rubber
Cable Gland	CI. IS 210 FG 260
Rubber gromate	Nitrial Rubber
Eye bolt	S.S
Winding Coil	Copper
Oil Chamber	CI. IS 210 FG 260
Oil	20W40
Flange	CI. IS 210 FG 260
Pump Casing	CI. IS 210 FG 260
Impeller lock Nut	S.S
Wearing Ring	CI. IS 210 FG 260
Strainer	S.S
Spiral Plate	CI. IS 210 FG 260
Impeller	CF8M
Mehanical Seal	SIC/SIC & TC/TC
Moisture Seal	Aluminium
Bearing Housing	CI. IS 210 FG 260
Ball Bearing D/E	C.S (SKF)
Bearing cover	CI. IS 210 FG 260
Rorot Shaft	S.S 410
Rorot Diecast	CRNO + Allu
Stator stamping	CRNO
Motor Body	CI. IS 210 FG 260
Outer Jacket	S.S
Ball Bearing N/D	C.S (SKF)
Top Cover	CI. IS 210 FG 260
Stand	M.S Fabricated
