Product Description
Features
- Pump and motor are in a single unit, which is why there is no need for alignment or coupling.
- The wet type, water cooled and lubricated type motor is suitable for 3 phase 415 V and single phase 230 VAC. supply.
- A PVC coated / Poly coated wire is used for the motor.
- Stators and Rotors produced with quality silicon stamping can lower the losses and increase motor efficiency.
- Varnish is filled in the Stators and Rotors under vacuum and baked under controlled temperature to achieve hard finish.
- All rotating components of the pump, such as impellers and rotors are dynamically balanced.
- The submersible pump can withstand variation of supply voltage.
- It is completely submerged in water, thus there is not requirement of priming.
- No pump house is needed and initial investment is low.
- High overall efficiency results in reduced electricity bills.
- Pollution free - no oil/ grease contamination.
- All C.I. parts are in line with the IS-210 FG 200.
Applications
- Domestic water supply
- For supplying water from underground tank to overhead tank in high rise residential and buildings.
- AGRICULTURE: For open well application, where there is no steadiness in water level.
- INDUSTRIES: For storage tank filling, water circulating system, etc.
Agriculture Application:
- Tubewell Irrigation
- Drip Irrigation / Sprinkler Irrigation
- River/Canal
- Openwell Irrigation
Public Utilities Application:
- Rural Water Supply
- Domestic Water Supply
- Urban Water Supply
Industries Application- Booster Application
- Raw & Treated Water Services
- Service Water Supply
- Fire Fighting Services
- Process & Cooling Water Circulation
- Mining & Construction Sites
- Ornamental Like Fountains
Technical Specification
| Borewell Dia. | Model | Head (meters) | Capacity (L.P.M.) | H.P. | Supply |
| 80 mm | JT Series | 8-100 | 20-65 | 0.5 to 1.25 | Single Phase |
| 100 mm | JA Series | 10-200 | 20-300 | 0.5 to 3
1.0 to 7.5 | Single Phase
Three Phase |
| 125mm | JF Series | 10-200 | 40-550 | 3.0 to 12.5 | Three Phase |
| 150 mm | JS Series | 15-250 | 80-1300 | 3.0 to 30.0 | Three Phase |
| 200 mm | JC Series | 10-200 | 200-2200 | 5.0 to 72.0 | Three Phase |
| 250 mm | JO Series | 10-150 | 1000-3500 | 10 to 100 | Three Phase |
| Description | Material |
| Shaft | S.S 40 |
| Suction Bush | LTB 4 |
| Suction | C. I |
| Necking | Nitrial Rubber |
| Sleeve | S.S 410 |
| Stage Bush | NIT Rubber/ LTB 4 |
| Impeller | AISI 410 |
| Stage Casing | C.I |
| N.R .V Flap | S.S |
| N.R .V | C.I |
Motor
| Qty | Description | Material |
| 1 | Motor Base | C.I FG 200 |
| 1 | Lower Housing | C.I FG 200 |
| 1 | Upper Housing | C.I FG 200 |
| 1 | Connection Piece | Nitrile Rubber |
| 1 | Sand Gurd | S.S 410 |
| 1 | Couple | S.S 410 |
| 2 | M.S Flange | M.S |
| 4 | Bearing Bush | LTB-4 |
| 1 | Rocker Support | S.S 410 |
| 1 | T.B Set | S.S V/S Taflon |
| 1 | Winding | C.S + Stamping |
| 1 | Stator | S.S + Stamping |
